DT Swiss launch first ever Cargo wheelset with Omnium
Here at Omnium we are committed to innovation, durability and performance, and are excited to announce our new custom wheelset with DT Swiss
For over 30 years DT Swiss has been building and innovating bicycle components of the highest quality. Known for combining Swiss craftsmanship with cutting-edge design to deliver products with lightweight performance, durability and reliability. Their wheels are the choice of high-performing athletes and everyday cyclists alike, whether you’re racing cross-country, touring cross-continent, descending alpine trails, or pushing heavy loads around town, DT Swiss wheels are a global benchmark for quality and consistency.
As cargo bikes become a bigger and bigger part of modern urban mobility, the considerations for wheel builders evolve with it. We need to consider different wheel diameters and the need for reinforced rims to bear more and more weight. After building many wheels for our clients on their custom bike builds over the years, we can now finally offer a custom DT Swiss wheelset designed for our bikes.
THE TRUE MARMALADE TEST
There’s so many thoughts bouncing around in my head while on tour, whether it’s where I’m gonna sleep, how I’ll find food or water, is that person texting and driving gonna stay in their lane…but one of the things I don’t need to ever think about is if the bike and the components on it will be durable enough to withstand the nonsense I put them through.
Having reliable gear on board is key and this wheelset from DT Swiss has held up through all manner of terrain, ups and downs over multiple mountain ranges and the roughest roads for the last 10,000km, and I trust will continue to keep me rolling for another 100,000km no problem.
Testimonial & photos by Truemarmalade
| SPECIFICATIONS | REAR WHEEL | FRONT WHEEL | DYNAMO WHEEL |
|---|---|---|---|
| Rim Weight | 760g | 500g | 500g |
| Wheel Weight | 1414g | 880g | 1150g |
| Max Carrying Capacity | 180kg | 180kg | 180kg |
| Rim Material | Aluminum | Aluminum | Aluminum |
| Rim Model | U663 | U663 | U663 |
| Tire Interface | Hooked / Crotchet tubeless TC | Hooked / Crotchet tubeless TC | Hooked / Crotchet tubeless TC |
| Valve Hole | Presta | Presta | Presta |
| Rim Diameter | 29″ / 700C | 20″ / 406 | 20″ / 406 |
| Rim ERD | 599mm | 383mm | 383mm |
| Rim Hight | 22mm | 22mm | 22mm |
| Inner Width | 30mm | 30mm | 30mm |
| Outer Width | 35mm | 35mm | 35mm |
| Holes | 32 | 32 | 32 |
| Hub Type | 370 | 370 | 370 |
| Axle System | 12mm Thru Axle | 15mm Thru Axle | 15mm Thru Axle |
| Built-In Dimension | 142mm | 100mm | 100mm |
| Brake Interface | Disc 6 Bolt | Disc 6 Bolt | Disc 6 Bolt |
| Cassette Interface | Shimano Road (HG) | – | – |
| Freehub Body | Shim. RD. 11SP Forged (ASF11) | – | – |
| Freehub System | Ratchet LN 18 | – | – |
| Spokes | Alpine II Spokes 2.34 / 291 + 289 mm | Alpine II Spokes 2.34 / 291 + 289 mm | – |
| Nipples | Aluminum Hex nipples 2.0 x 14 | Aluminum Hex nipples 2.0 x 14 | – |
| Compatability | Wifi, V3 & V3.1 | Wifi, V3 & V3.1 | Wifi, V3 & V3.1 |
We are excited to introduce this new DT Swiss wheelset designed specifically for Omnium, with intended use on our bikes such as the mini, mini-max and cargo. This collaboration is an important milestone in adapting high-performance engineering to the unique challenges of heavy-load, utility-focused cycling. Where strength, stability, and long-term use are key. By applying their experience in spoke, hub, and rim design to a different kind of riding need, this collaboration highlights how performance technology can be adapted to support everyday transport. It reflects a shift toward practical, purpose-driven cycling without leaving behind the precision and standards DT Swiss is known for.
Available from July 3rd via our Webshop and dealers.
